Project Description

Zigbee ON/OFF Lighting Relay Switch

Control a room lightings with a smartphone, by voice or automatically

The Zigbee ON/OFF Lighting Relay Switch allows you to connect one or several lightings to control it by voice (via a voice assistant), via a smartphone or a tablet or automatically through the light scenario of your choice. It is quick to install to the ceiling, behind the existing wall switch or at the electrical panel thanks to the Din Rail Box . This ON/OFF Lighting Relay Switch is Zigbee 3.0 certified, compatible with the ecosystems and voice assistants such as Amazon Echo, Philips Hue, Ikea Trädfri, etc. With its two channels, it allows to control one or several lightings. The zero crossing feature allows a compatibility with all types of lamps.

Zigbee 3.0 certified

This ON/OFF Lighting Relay Switch is Zigbee 3.0 certified allowing you a full interoperability with the products that integrate the relay switch profile. You can create your Zigbee ecosystem and make it evolve.

Voice or remote control

You can control the ON/OFF Lighting Relay Switch thanks to a Zigbee compatible controller, your smartphone (via your gateway app) or by voice through your compatible voice assistant.

Zero crossing feature

The ON/OFF Lighting Relay Switch has a zero crossing feature, allowing a compatibility with all types of lamps.

Quick installation

Install in only few minutes your Zigbee relay switch, whether it is in a mounting pot or at the electrical panel with NodOn DIN Rail Box.

Ultra compact profile

This ON/OFF Lighting Relay Switch is a concentrate of innovation in an ultra-compact box, allowing you an installation in flush-mounting pots >30mm.

Update Over The Air

Thanks to the OTA Zigbee feature, your relay switch will always benefit the latest updates. The updates can be carried out via a compatible gateway.

Control via smartphone or by voice

With my Zigbee ON/OFF Lighting Relay Switch, I can:

Lightings centralization

Technical specifications

Power supply: 230V AC ~ 50Hz
Switching capabilities: 230V AC – 2 x 3A
Consumption: <1W
Maximum output power: 2 x 690W – zero crossing
Radio frequency range: 2.4 GHz
RF power max: +10dBm
Range: up to 30m indoors
Operational temperature: -20°C to 60°C
Protection rating: IP 30
Device ID Type: On/Off Light (0x0100)
Dimensions: 40 mm (l) x 44 mm (L) x 16.9 mm (h)

SIN-4-1-20 – Zigbee ON/OFF Lighting Relay Switch
